Name：CPD10W Counterbalanced Electric Stacker
Click to view larger
Diagrams：

Products List
Portable Drum Handling Equipment
Drum Dumping Equipment
Hydraulic Drum Stacker
Forklift Mounted Drum Grabber
Forklift and Crane Mounted Drum Handler
Below Hook Drum Lifter
Oil Drum Tool and Accessories
Gas Cylinder Handling Trolley
Mobile Scissor Lift Table
Stationary Lift Platform
Acess Lift Platform
Mini Pallet Stacker
Work Positioner
Platform Hand Trolley
Roll and Reel Handling Equipment
Pallet Tilter
Hoisting and Lifting Equipment
Pallet Truck
Mate Series Lift Trucks
 Hand Pallet Truck
 Electric Pallet Truck
 Electric Stacker
 Reach Truck
 Counter-balanced Eletric Forklift
 Electric Tow Tractor
Forklift Attachments
Electric tow Tractor and Tugger

 Business Line: 4007-166-180
 Tel：+86 21 58003681
              +86 21 68014500
 Fax：+86 21 68014262
 Website：http://www.sinoliftdrum.com
 Email：drum@sinolift.com
 Skype：sinolift

Feature：
The SINOLIFT counterbalanced Electric Stacker is the ideal combination of forklift and truck - it is best suited for cargo handling tasks where straddle legs or outriggers cannot work.
Storage racks and sections with bottom rails can restrict forward reach, and counterbalanced electric stackers are designed to address this limitation.
Electric Stackers are ideal for loading and unloading trucks or positioning materials and goods where shelving or machinery may have some sort of bottom interference. With no protruding legs, the Electric Stacker allows unobstructed access to the work area.
The SINOLIFT counterbalanced Electric Stacker is your versatile and cost effective alternative to sit-down forklifts, Electric Stacker providing you with an efficient work cycle at half the operating cost of a walker.
Specifications：
Manufacturer SINOLIFT
Model
Electric Stacker
CPD10W
Electric Stacker
CPD15W
Power Type Electric
Type of Operation Stand-on
Steering Mode EPS
Load Capacity/Rated load Q kg 1000 1500
Load Center Distance C mm 500 500
Load Distance,Center of Drive Axle to Fork x mm 130 130
Wheelbase y mm 1300 1450
Total Weight(with Battery) kg 1830 1850
Axle Load (laden):Drive side/Load side kg 1043/787 1055/795
Axle Load (unladen):Drive side/Load side kg 340/2490 400/2950
Overall Length (Pedal Retracted/Expanded) L1/L2 mm 2730/3170 2880/3320
Frame Length (Pedal Retracted/Expanded without fork) mm 1655/2075 1820/2245
Overall Width W1/W2 mm 880/1030 880/1030
Lifting Height h1 mm 3000 3000
Lowered Mast Height h2 mm 2050 2050
Extended Mast Height h4 mm 3855 3855
Fork Dimension l/e/s mm 1070×100×40 1070×100×40
Fork Mounting Class 2A 2A
Fork Carriage Spread Width b2 mm 220-700 220-700
Fork Carriage Width mm 737 737
Ground Clearance at Center of Wheelbase (Min.) m1 mm 50 50
Height of Operating Handlebar (Min./Max.) h14 mm 1000/1450 1000/1450
Turning Radius Wa mm 1560/2000 1710/2145
Min.Aisle Width (Pallet size 1000*1200)(PedalRetracted/Expanded) 3050/3470 3195/3620
Min.Aisle Width (Pallet size 800*1200)(Pedal Retracted/Expanded) 3165/3605 3315/3750
Tyre Type Polyurethane Polyurethane
Tyre Size (Front) mm φ210x85 φ210x85
Tyre Size (Auxlliary Wheel) mm φ115x55 φ115x55
Tyre Size (Driving Wheel) mm φ230x75 φ230x75
Wheels Quantity, front/rear(x=Driving Wheels) 2/1x+2 2/1x+2
Traveling Speed (laden/unladen) Km/h 5/6 4.5/5
Lifting Speed (laden/unladen) mm/s 80/110 80/110
Lowering Speed (laden/unladen) mm/s 140/120 140/120
Max. Gradient Performance s2 5min (laden/unladen) % 5/8 5/8
Service Brake Type Electromagnetic
Parking Brake Type Electromagnetic
Drive Motor Rating (AC)S2 -60min kW 1.5 1.5
Lift Motor Rating (DC)S3-15% kW 2.2 2.2
Battery Voltage/Capacity K5 V/Ah 24/210 24/210
Battery Weight kg 188 188
Controller Brand CURTIS CURTIS
Controler Model 1232E 1232E
Sound Level at Driver's Ear according to EN 12053 dB 70 70
