Manufacturer
|
SINOLIFT
|
|
Model
|
EPT20K
|
EPT20-Li
|
|
Power Type
|
|
|
AGM
|
LEP
|
|
Type of Operation
|
|
|
Pedestrian
|
Pedestrian
|
|
Load capacity/Rated load
|
q
|
kg
|
2000
|
2000
|
|
Load Center Distance
|
c
|
mm
|
600
|
600
|
|
Alex centre to Fork Face
|
x
|
mm
|
948
|
948
|
|
Wheelbase
|
y
|
mm
|
1265
|
1265
|
|
Total Weight (with battery
|
|
kg
|
340
|
335
|
|
Tyre Type
|
|
|
Polyurethane
|
Polyurethane
|
|
Tyre Size( Load Wheel)Tandem
|
|
mm
|
φ80x60
|
φ80x60
|
|
Tyre Size (Load Wheel) Single
|
|
mm
|
φ210x70
|
φ210x70
|
|
Tyre Size (Drive Wheel)
|
|
mm
|
φ70x36
|
φ230x75
|
|
Wheels Quantity, front/rear (x=Driving Wheels
|
|
|
4/1x+2
|
4/1x+2
|
|
Track Width,Front,Driving Side
|
|
mm
|
520
|
520
|
|
Track Width,Rear,Loading Side
|
|
mm
|
400
|
400
|
|
Lifting Height
|
b10
|
mm
|
190
|
190
|
|
Height of Tiller Arm in Driving Position, Min.-Max.
|
b11
|
mm
|
950-1250
|
950-1250
|
|
Lowered Height
|
h3
|
mm
|
85
|
85
|
|
Overall Length
|
h14
|
mm
|
1620
|
1620)
|
|
Length to Fork Face
|
h13
|
mm
|
460
|
460
|
|
Overall Width
|
l1
|
mm
|
680
|
680
|
|
Fork Dimension
|
l2
|
mm
|
54x160x1150(1220)
|
54x160x1150(1220)
|
|
Fork Spread Width
|
b1
|
mm
|
560/680
|
560/680
|
|
Ground Clearance at Center of WVheelbase (Min)
|
s/e/l
|
mm
|
27
|
27
|
|
Aisle Width for Pallets 1000x1200 Crossways
|
b5
|
mm
|
2415
|
2415
|
|
Aisle Width for Pallets 800x1200 Crossways
|
m2
|
mm
|
2316
|
2315
|
|
Turning Radius
|
Ast
|
mm
|
1430
|
1430
|
|
Traveling Speed (Laden/Unladen)
|
Ast
|
km/h
|
2.5/3
|
2.5/3
|
|
Lifting Speed (Laden/Unladen)
|
Wa
|
mm/s
|
35/45
|
35/45
|
|
Lowering Speed (Laden/Unladen)
|
|
mm/s
|
50/40
|
50/40
|
|
Max.Gradient Performance (Laden/Unladen)
|
|
%
|
5/8
|
5/8
|
|
Service Brake Type
|
|
|
Electromagnetic
|
Electromagnetic
|
|
Driving Motor Rating (DC) S2 60min
|
|
kw
|
0.75
|
0.75
|
|
Lifting Motor Rating S3 15%
|
|
kw
|
0.8
|
0.8
|
|
Battery Type
|
|
|
Acid
|
Li-ion
|
|
Battery Voltage/Capacity K5
|
|
V/Ah
|
24/100(518*276*240mm)
|
48/30(size:120*220*340mm)
|
|
Battery Weight
|
|
kg
|
54
|
50
|
|
Charger
|
|
V/A
|
24/15
|
48/16
|
|
Controller Model
|
|
|
DC CURTIS
|
DC CURTIS
|
|
Steering Type
|
|
|
Mechanical
|
Mechanical
|
|
Sound level atdriver's ear according to EN 12 053
|
|
db(A)
|
70
|
70
|
Diagrams：
