Name:BBF2000 Big Bag Lifter
Click to view larger
Diagrams:

Products List
Portable Drum Handling Equipment
Drum Dumping Equipment
Hydraulic Drum Stacker
Forklift Mounted Drum Grabber
Forklift and Crane Mounted Drum Handler
Below Hook Drum Lifter
Oil Drum Tool and Accessories
Gas Cylinder Handling Trolley
Mobile Scissor Lift Table
Stationary Lift Platform
Acess Lift Platform
Mini Pallet Stacker
Work Positioner
Platform Hand Trolley
Roll and Reel Handling Equipment
Pallet Tilter
Hoisting and Lifting Equipment
Pallet Truck
Mate Series Lift Trucks
Forklift Attachments
Electric tow Tractor and Tugger

 Business Line: 4007-166-180
 Tel:+86 21 58003681
              +86 21 68014500
 Fax:+86 21 68014262
 Website:http://www.sinoliftdrum.com
 Email:drum@sinolift.com
 Skype:sinolift

Feature:

Big Bag Lifter BBF2000 is Suitable for forklift trucks and big bags

Suitable for lifting two big bags at the same.

Safe working load:2000kg

The maximum size of fork:180*60mm

Installation method: Slip-on

Unit weight: 153.5kg

Surface treatment: Painted finish.

Specifications:
Model BBF2000
load kg 2000
size of fork mm 180*60
Installation method Slip-on
Unit weight kg 153.5
Inner Position 1 2 3 4 5
L(mm) 1410 1535 1670 1805 1940
H(mm) 785 930 1060 1195 1330
Capacity(kg) 2*1000 2*910 2*830 2*760 2*710
